FF1400R12IP4 Infineon 1400A 1200V IGBT Module PrimePACK 3

Name: FF1400R12IP4 Infineon 1400A 1200V IGBT Module PrimePACK 3
Brand: Infineon Technologies
SKU: FF1400R12IP4
Price: 266.76 USD
Availability: InStock

Infineon TechnologiesSKU: FF1400R12IP4

Price:

$266.76 $288.99

Quantity:

✅ Genuine, verified
🚚 Ships within 1-2 business days
🌍 Ships to 40+ countries

Share this product

Parameter	Specification
Manufacturer	Infineon Technologies
Series	PrimePACK™ 3
Device Type	IGBT Module (Dual / Half-Bridge)
Configuration	Dual (Half-Bridge) with Emitter Controlled Diode
Collector-Emitter Voltage (VCES)	1200 V
Continuous DC Collector Current (ICnom)	1400 A (TH=60°C, Tvj max=175°C)
Repetitive Peak Collector Current (ICRM)	2800 A (tp=1ms)
Collector-Emitter Saturation Voltage (VCE(sat))	1.75 V (typical)
Gate-Emitter Peak Voltage (VGES)	±20 V
Power Dissipation	7.65 kW
Isolation Voltage	4 kV AC, 1 min
Integrated Temperature Sensor	NTC Thermistor
IGBT Technology	IGBT4 (Trench/Fieldstop)
Operating Junction Temperature (Tvjop)	150°C
Features	High short-circuit capability; high surge current capability; high current density; VCEsat with positive temperature coefficient; pre-applied thermal interface material; RoHS compliant
Applications	High power converters; motor drives; wind turbines; industrial power conversion
